R-RAWL-PSC40 Pneumatic steel and concrete nailer

Features and benefits

  • Pin range from 15mm to 40mm provides wide range of application
  • Tool free depth of drive adjustment provides precise fixing settings for any application
  • Special heat treated driver blade for prolonged life of the tool
  • Quick release mechanism for clearing obstructions and jams without the use of any tools. Allows also to perform simple maintenance
  • More powerfull than gas powered equivalent of the same specification. Up to 10% more power ensures outstanding performance in all applications and timber types
  • Reduced cost of consumables - no cartridges required
  • Magazine capacity 40 pins reduces reload time
  • Adjustable exhaust port is an improtant safety feature when operating in areas where other persons amy be affected by the exhausted air and particles

Applications

  • Cable conduits and wires installation
  • Applicable for fixing steel and aluminium profiles in drywall structures
  • Installation of all types of M&E clips and clamps

Equipment

  • R-RAWL-PSC40  Pneumatic steel and concrete nailer
  • Operating and Safety manual
  • Safety glasses

Product information

Index

Power source

Magazine type

Magazine capacity

Magazine angle

WEIGHT

Fastener diameter range

Fastener length range

Noise level

Maximum pressure

Operating pressure

Dimensions

Box weight

Outer weight

EAN

[nail]

[degree]

[kg]

[mm]

[mm]

[dB]

[bar]

[bar]

[mm]

kg

kg

R-RAWL-PSC40

Pneumatic

Strip

40

0

3.4

2.6 - 3.0

15 - 40

87

8

5-7

437x120x320

4.41

8.81

5906675062587
