R-WW90II-XS1 Gas Wood Nailer - Carton Packing

Features and benefits

  • Nails range from 50mm to 90mm provides wide range of application
  • Lithium technology alongside with energy saving features ensures high capacity and performance of the system
  • Compact and ergonomic design allows the operator to achieve great accessibility and freedom of operation
  • Low failure rate provides low runnig cost of the system
  • Rear loading magazine with a capacity of 60 nails. Quick and simple to load thanks to one hand operation feeder spring. A safety clip at the rear prevents the nails from falling out and ensures safe reloading
  • Retractable rafter hook ensures safe storage of the tool when not in use. Can also be hung from a tool belt for complete maneuverability
  • Simplified depth adjustment design provides the end user with easy but accurate depth of drive control
  • Sequential firing mode for operators safety and fixing precision
  • Removable no mark nose for protecting the timber surface. Especially important when securing timber cladding or facades
  • Tool free depth adjustment. The operator can easily adjust the depth that the nail is driven into timber to produce a precise fixing

Applications

  • Timber frame stud work in timber framing industry
  • Installation of battens and sheating in roof construction
  • Manufacturing of timber standarised structure like Timber frame houses or roof elements
  • Installation of soffits and other roof finishing elements
  • Installation of wooden facades and other external trim
  • Installation of timber flooring and terraces

Equipment

  • R-WW90II Gas powered nailer
  • 1 battery
  • Charger base
  • AC power supply cable
  • Operating and Safety manual
  • Safety glasses and ear plugs
  • Carton box

Product information

Index

Fastener length range

Substrate

Dimensions

Fuel cell type

WEIGHT

Magazine capacity

Battery charge

Shots per charge

Noise level

Box weight

Outer weight

EAN

[mm]

[mm]

[kg]

[nail]

[h]

[dB]

kg

kg

R-WW90II-XS1

50 - 90

Timber

367 x 372 x 108

GP6

3.8

60

2

8000

94

5.80

11.60

5906675484495

R-WW90II-XS

50 - 90

Timber

367 x 372 x 108

GP6

3.8

60

2

8000

94

5.80

11.60

5906675493572

Additional information
